Parameters

Drive unit

Electric

Load Capacity

Kg

1500

Load center

mm

600

Brake way

电磁失电制动

Wheels and tyres

Tyre type

Polyurethane

Front tyre dimensions

mm

φ80×70

Traction wheel

mm

φ210×70

Wheels quantity front/rear(x=traction)

1x-4/1

Dimensions

Travel position tiller height

mm

700-1000

Fork lift height

mm

115

Forks clearance from the ground

mm

≤80

Fork dimensions

S/L1/E

(mm)

1178×160×53

Total length

mm

1275

Total width

mm

550

Minimum turning radius

mm

1400

Performance

Traction speed(lade/unlade)

Km/h

4.6/4.2

Maximum grade ability (lade/unlade)

％

6/3

Weight

Truck weight (without battery)

Kg

115

Motors Battery

electrical engineering control system

直流

Traction motor

KW

0.65

Battery volts/ampere

V/Ah

24V/25Ah

Battery Charger

Input

AC V/Hz

220V/50(60)HZ

Output

DC V/A

24V/10A
