SEH Hand Stacker
Item No.:CTY-SEH
Manual staker,Man push
Description
Item specifics
Ideal and economic choice for manual transport and lifting different heights (2000,2500,3000mm) and deverse capacities(1000kg,1500kg,2000kg) ensure to deal with a large number of applications.
| Model | CTY-SEH1.0 | CTY-SEH2.0 |
| Rated lifting capacity(kg) | 1000 | 2000 |
| Max.lifting height(mm) | 2000/2500/3000 | 2000/2500/3000 |
| Lowered height of forks(mm) | 90 | 90 |
| Fork length(mm) | 900 | 900 |
| Adjustable width of forks(mm) | 340-770 | 360-770 |
| lifting speed(mm/s) | 20 | 14 |
| Lowering speed(mm/s) | Adjustable | Adjustable |
| Outer width of front legs(mm) | 690 | 690 |
| Operation power of carank(kg) | 24 | 32 |
| Front wheel size(mm) | φ74×52 | φ74×70 |
| Rear wheel size(mm) | φ180×50 | φ180×50 |
| Overall size(mm) | 1410×780×1540/1790/2040 | 1410×780×1540/1790/2040 |
| Truck weight(kg) | 200/220/240 | 200/250/280 |
