General

1

Model

FDR30

FDR35

2

Power Type

Diesel

Diesel

3

Rated Capacity

kg

3000

3500

4

Load Centre

mm

500

500

Characteristic&Dimension

5

Lift Height

mm

3000

3000

6

Fork Size

L×W×T

mm

1220×125×45

1220×125×50

7

Mast Tilt Angle

F/R

Deg

10°/12°

10°/12°

8

Front Overhang (Wheel center to fork face)

mm

684

699

9

Ground Clearance（Bottom of mast）

mm

270

270

10

Overall Dimension

Length to face of fork(Without fork)

mm

3252

3252

11

Overall Width

mm

1835

1835

12

Mast Lowered Height

mm

2230

2260

13

Mast Extended Height(With backrest)

mm

4280

4260

14

Overhead Guard Height

mm

2250

2250

15

Turning Radius (outside)

mm

4380

4380

16

Min. insecting aisle

mm

3040

3040

Performance

17

Speed

Travel (Full load)

km/h

25

25

18

Lifting (Full load)

mm/s

480

480

19

Max.Gradeability (No load/Full load)

%

30

30

Chassis

20

Tire

Front

mm

405/70-20-14PR

405/70-20-14PR

21

Rear

mm

10.0/75-15.3-12PR

10.0/75-15.3-12PR

22

Wheelbase

mm

1990

1990

23

Service weight

kg

5700

5900

Power&Transmission

24

Battery

Voltage/Capacity

V/Ah

12/120

12/120

25

Engine

Model

4H50TIC

26

Manufacture

HATZ

27

Rated output/r.p.m.

kw

54.9/2600

28

Rated torque/r.p.m.

N·m

240/1600-1900

29

No.of Cylinder

4

30

Bore×Stroke

mm

84×88

31

Displacement

cc

1952

32

Fuel Tank Capacity

L

80

80

33

Transmission

Type

Hydraulic

Hydraulic

34

Stage

FWD/RVS

3/2

3/2

35

Driving Type

2WD/4WD

2WD/4WD
